Jensen speaker model?

Discussion in 'Amps/Cabs Tech Corner: Amplifier, Cab & Speakers' started by Tone Loco, Feb 28, 2009.

  1. Tone Loco

    Tone Loco Silver Supporting Member

    Messages:
    4,211
    Joined:
    Apr 20, 2004
    Location:
    Boston
    Any idea what this is? No numbers on the frame and it all looks pretty new to me, not as dusty as a lot of old speakers I've seen but the label seems to be off of a 60's Jensen as far as I can make out from hunting around on the web. I assume it is a recone and there are some numbers on the cone, last shot, but I see now that they aren't too clear... unfortunately I already put it back in the cab. It came in a 63-64 Fender Deluxe but the cabinet isn't original and neither is this as far as I know. Anyhow, just curious.

    [​IMG]


    [​IMG]

    [​IMG]

  2. SatelliteAmps

    SatelliteAmps Member

    Messages:
    6,178
    Joined:
    Oct 19, 2007
    Location:
    Normal Heights, Calif
  3. Trout

    Trout Member

    Messages:
    7,566
    Joined:
    Jun 23, 2006
    Location:
    Illinois/Far West Burbia

    Think so?

    The magnet looks way to big to be the C12R,
    My bet is on C12N, more in line with the magnets size and frame design.

  4. Swarty

    Swarty Member

    Messages:
    1,132
    Joined:
    Dec 16, 2003
    Location:
    Michigan
    With you 100% Trout.

  5. Tone Loco

    Tone Loco Silver Supporting Member

    Messages:
    4,211
    Joined:
    Apr 20, 2004
    Location:
    Boston
    So does it look like a recone or new frame or is that how they looked? It seems like its in awfully good shape for a 40+ year old speaker.

  6. Swarty

    Swarty Member

    Messages:
    1,132
    Joined:
    Dec 16, 2003
    Location:
    Michigan
    Likely a recone. A new frame would be a new speaker.

  7. slider313

    slider313 Silver Supporting Member

    Messages:
    7,636
    Joined:
    Jul 28, 2005
    Location:
    NC
    That's an Eminence,like the ones in the HR Deluxe, with a Jensen label.
    What are the numbers on the cone?

  8. Tone Loco

    Tone Loco Silver Supporting Member

    Messages:
    4,211
    Joined:
    Apr 20, 2004
    Location:
    Boston
    I'm inclined to agree at least about the label being on a new speaker.
    Like I said its back in the cab but looking at the pictures I'd say (without a lot of confidence other than the "99 " on the second one) the numbers are:

    4512419
    99 032

    I thought maybe it was a relabeled new Jensen, the frame looks like these pictures: http://jensentone.com/c12n.php There's are vertical ribs on the frame like on that jensen that you can't see well on the pictures I took. The cone seems to have more ridges than whats in that Jensen RI picture though.

    How would you get that label off an old speaker? Seems really hard to do but it is kind of scraped up. Would you steam it off or something? Where there's a will there's a way I guess.

  9. slider313

    slider313 Silver Supporting Member

    Messages:
    7,636
    Joined:
    Jul 28, 2005
    Location:
    NC
    They were selling those Jensen decals on ebay a couple of years ago.
    A hair dryer can be used to heat the magnet and the sticker/decal will just peel right off.

  10. Trout

    Trout Member

    Messages:
    7,566
    Joined:
    Jun 23, 2006
    Location:
    Illinois/Far West Burbia
    I agree,

    I doubt thats a Jensen Frame, The speaker terminal is not correct to Jensen either.

  11. SatelliteAmps

    SatelliteAmps Member

    Messages:
    6,178
    Joined:
    Oct 19, 2007
    Location:
    Normal Heights, Calif
    Really bad guess on my part. Sorry. Looking again, I think the emminence vote is correct.

  12. phsyconoodler

    phsyconoodler Member

    Messages:
    4,333
    Joined:
    Jul 11, 2005
    Location:
    calgary canada
    Who really cares if it's a Jensen or an Eminence?Both were not great sounding speakers.OK is all they ever were.I have seen more of those 'special design' speakers with seized voice coils in Hot Rod Deluxes.
    Fender had bean counters too.The cheaper the better for production madels.
    It lookslike an Eminence speaker I have that's labelled Jaguar in a Randall amp.

    Last edited: Feb 28, 2009
  13. Abe

    Abe Member

    Messages:
    571
    Joined:
    Nov 17, 2004
    I think Jensen made some of the best sounding speakers ever. I doubt I'm alone either. Many of the newer Eminences are quite nice sounding too. Certainly more than ok in my opinion.

  14. phsyconoodler

    phsyconoodler Member

    Messages:
    4,333
    Joined:
    Jul 11, 2005
    Location:
    calgary canada
    I agree they did,but the 'special design' ones in production amps were cheaper quality to save money.

  15. slider313

    slider313 Silver Supporting Member

    Messages:
    7,636
    Joined:
    Jul 28, 2005
    Location:
    NC
    Actually, the special design ones with the brown&gold labels were an are some of the best sounding speakers in blackface Fenders,specifically the C10P,C10N,C12P and C12N. Leo Fender had a hand in that by having Jensen use a higher temperature voice coil and different cones because by the late 50's and early '60's his higher powered amps were blowing speakers. Most people call the C12N a 25 watt speaker,which is what the earlier ones were rated but I believe the rating on the brown&golds to be closer to 40 watts. Would Leo use two 25 watt speakers in his blackface 80 watt Twin Reverb?

  16. slider313

    slider313 Silver Supporting Member

    Messages:
    7,636
    Joined:
    Jul 28, 2005
    Location:
    NC
    Definitely not a Jensen by the frame and the numbers on the cone. Jensen cones started with a 301... I'm 99% positive that's a Fender Eminence and the exact same speaker that's used in the Fender HR Deluxe.

  17. jsm355

    jsm355 Member

    Messages:
    173
    Joined:
    Jul 16, 2008
    Location:
    NYC
    I happen to have a pair of Jensens that I purchased back in 1976 . Old Twin speakers .
    the #'s on mine are listed on the outer frame ...they are 12NA's ...
    Jenson code # 220711. I also have another # the rim C12NA - C82206 & 023119
    I needed to recone these in 1980 to match the power of a Lab Series L-5 Amp w/ an
    extra-heavy duty 1.75 " Voice coil . I remember Killer sounds from these . Still have them but not in service at the time .

  18. jsm355

    jsm355 Member

    Messages:
    173
    Joined:
    Jul 16, 2008
    Location:
    NYC
    As I remember the 220 was the Jensen company code followed by < this where I may have it mixed up > last digit of the year then the week of production . Since I got mine in mid to late 1970's & no later than 1980 my speakers could be either 1967 or 1977 !! I too have been trying to find out the DATE of these speakers !
    I also have 24 ribs on the cone !!

    Last edited: Nov 3, 2009
  19. slider313

    slider313 Silver Supporting Member

    Messages:
    7,636
    Joined:
    Jul 28, 2005
    Location:
    NC
    Jensen was out of business by 1973, so yours would be 1967.
